For a singer-songwriter performing on stage or giving a concert in a living room, sound is everything.
LD Systems FX 300 will blow you away right from the moment you start your show, even if you've had little to no time to carry out a soundcheck. This small yet handy device not only serves as an effect pedal for altering the sound of your voice and instrument but is also an easy-to-use two-channel mixer. Its best feature by far are the pedals that let you control the mute functions with your feet or hand. And if you've got something to say, you can simply mute all effects with the FX MUTE pedal so your voice can be heard loud and clear without any reverb or delay and everyone in the room can understand your message. To prevent the signal of your microphone or instrument from reaching the outputs, all you need to do is tap the MUTE ALL pedal - a lifesaver during breaks or when wrapping up your set.
The FX 300 is outfitted with 16 digital effects presets in 16-bit quality, two inputs with a separate gain setting and a balanced and unbalanced output. The 48 V phantom power provided at the microphone input allows condenser microphones to be used in addition to dynamic microphones. The high-impedance, low-noise instrument input is not only great for acoustic or bass guitars but also for all other instruments. Plenty of headroom ensures you no longer have to worry about distorted signals. And with a 9 V battery that lasts up to five hours, LD Systems FX 300 has got you covered even if there's no outlet in sight.
Product type |
Artist Pedal |
Type |
Home-Recording, Live |
Channels |
2 |
Microphone channels |
1 |
Mic inputs |
XLR/6.3 mm jack |
Frequency Response Microphone Channel |
50 - 20000 Hz |
Amplification range Microphone channel XLR input |
42 dB |
Mono Mic Input Input THD-N |
<0,03% |
Impedance XLR input |
6000 Ohm(s) |
Phantom power |
48V DC to XLR Input |
Microphone channel Jack input Input type |
Electronically balanced |
Amplification range Microphone channel Jack input |
20 dB |
THD jack input |
<0.045% |
Microphone Equalizer |
5/-8dB @ 8kHz |
Microphone channel controls |
FX SEND, Gain, tone |
Microphone Channels Display Elements |
channel signal |
Instrument inputs |
1 |
gain range |
23 dB |
THD |
0.03% |
Equalizer |
7/-8dB @ 10kHz |
Channel Inserts |
1 |
Controls |
FX SEND, Gain, tone |
Indicators |
3-colour LED (SIG), channel signal |
Line outputs |
2 |
Line output connectors |
6.3 mm TRS, XLR |
Output level XLR |
Max. 17dBu, balanced |
Impedance XLR output |
150 Ohm(s) |
Output level Jack output |
Max. 5dBV, unbalanced |
Impedance jack output |
40 Ohm(s) |
Digital Effects Processor |
Yes |
Number of Presets |
16 |
Main section controls |
DFX Presets, FX MUTE, MIX OUT, MUTE ALL, Power |
Display elements Main section |
Effekt-Clip, FX MUTE, MUTE ALL, red LED (FX CLIP) |
Operating voltage |
9 V block, External mains adapter 9 V DC / 250 mA (not included |
Ambient temperature (in operation) |
0 - 40° °C |
Relative Humidity |
< 80% (non-condensing) |
Width |
160 mm |
Height |
55 mm |
Length |
163 mm |
Weight |
0,65 kg |
Features |
Preparation for microphone stand mounting |
