Product Details
+
2-8 DMX / RDM Booster, 5-pin XLR
- OLED Display
- Isolated outputs
- 2 inputs, selectable outputs
- Multiple monitoring functions
The Booster Pro is the ultimate DMX tool which should be in the equipment rack of each rental company or installation. The Booster Pro is an optical isolated DMX Splitter and Booster. The Booster Pro has 2 inputs which can be patched to 8 selectable output (for each output you can patch input A or B). The Booster Pro is fully RDM compatible and offers real-time DMX monitoring. For specialist applications the DMX timing can be adjusted. Furthermore each output of the Booster Pro has a monitoring function which controls the status of the connected cables real-time. In case of any failure an acoustical signal will warn the user. The intuitive OLED display lets you set all the different function fast and easily.
Specifications
Electrical Specifications and Connections
Power Supply | 100-240 VAC 50-60 Hz |
Power Consumption | 5 W |
Power Connector in | Power Pro Blue |
DMX Connector | XLR 5P In/Out |
DMX Connector in | XLR 5P |
DMX Connector out | XLR 5P |
Product code 50789
EAN 8717748422774
