FEATURES:

• 6K @75fps* & 4K @100fps max
• 10-bit color
• Super 35mm CMOS sensor
• 14 stops dynamic range
• ZRAW supported
• EF / PL lens mount
• Gigabit Ethernet for data, control & live streaming with Z CAM E2 sync cable (not included)

SPECIFICATIONS:

Sensor

• Type: Super 35mm CMOS Sensor
• Size: 37.09 x 24.75 mm
• Effective Pixels: 26 Megapixels
• 14 stops of Dynamic Range

Camera

• Lens Mount:  EF / PL (different hardware variants)
• On-Board Mic:  Stereo
• Recording Media:  1 CFAST  2.0 slot

Resolution & Max Frame Rate

• 6244x4168 @30fps max (6K Open Gate)
  6144x3240 @48fps max (DCI 6K)
  6144x2592 @60fps max (DCI 6K 2.4:1)
  5760x3240 @48fps max (6K UHD)
  5552x4164 @30fps max (5K 4:3)
  4992x4160 @30fps max (5K 6:5)
  4096x2160 @72fps max (DCI 4K) *
  4096x1728 @120fps max (DCI 4K 2.4:1)
  3840x2160 @72fps max (4K UHD) *
  3840x1620 @90fps max (4K UHD 2.4:1)
  1920x1080 @120fps max (FHD)

  * Cropping / Supersampling selectable

I/O Connectivity

• Video Connectors
• HDMI 2.0 Type A (video output up to DCI 4K @60fps, 10-bit 4:2:2)

• Audio Connectors
• 3.5 mm stereo jack socket for active microphone only, or 5-pin LEMO port for dual channel XLR microphone (requires additional XLR audio connector)
• 3.5 mm stereo jack socket output

• Other
• 1 x USB Type-C
• 2 x Serial Port
• 2.5 mm jack socket (Sony LANC compatible)

• Wireless
• 5G, 802.11n with external antenna port

Power

• Battery Type
• Sony NP-F series compatible (Battery not included)
• Power Output: DC 12V (2-pin LEMO socket)

• Connectors
• DC 12V (2-pin LEMO socket), with LEMO connector

Temperatures

• Operating
• 32 to 104°F / 0 to 40°C

• Storage
• -4 to 140°F / -20 to 60°C

Physical

• Mounts
• 1/4"-20 Tripod mount
• 8x 1/4"-20 Accessory mounts

• Construction
• Aluminum

• Dimensions
• 91.2 mm x 99.2 mm x 99.1 mm (without lens)

• Weight
• TBD

Package Weight

• TBD

INCLUDED:

• Z CAM™ E2-F6 Full-Frame Camera Unit
• AC/DC Power Adapter
• Power Cables (US / EU / UK)
• Quick User Guide
• Warranty Card
